Flexity Tramcar M33
The tramcars of the type M33 have been adapted to the infrastructure and the environmental conditions in Gothenburg. The tramcars are delivered in several variants; the first ones are three-part, uni- or bidirectional vehicles. The multifunctional areas in the vehicles are intended for wheelchairs, walking frames and prams.
The reliable and innovative electrical equipment in the vehicles have been supplied by Kiepe Electric. Kiepe Electric has supplied e.g. the complete traction equipment and the vehicle control devices. Together with the bogies from Bombardier this electrical equipment ensures smooth and comfortable journeys.
The traction motors are liquid-cooled. An advantage of the vehicles is the recovery of the motor heat for the heating of the passenger compartment, which is environment-friendly and reduces the energy consumption of the vehicles and thus their life cycle costs.
Project Characteristics
- Three-part articulated uni- or bidirectional vehicle. Optional: five-part multi-articulated vehicle
- 100% low-floor vehicles
- Air-conditioned passenger compartment and driver’s cab
- Liquid-cooled traction motors, cooling unit combined with braking resistor
- Innovative motor heat recovery to heat the passenger compartment
- Video monitoring in the vehicle and camera rear-view mirror outside
- Passenger infotainment and passenger Wi-Fi
- Emergency operation possible with on-board battery, i.e. without line voltage
Vehicle Data
Vehicle length | 33 m |
---|---|
Vehicle width | 2,650 mm |
Vehicle height | 3,600 mm |
Low-floor proportion | 100 % |
Tare weight | approx. 48 t |
Gauge | 1,435 mm |
Doors | 10 passenger compartment doors |
Seats | 63 |
Standee | 157 |
Wheel diameter | 630 mm (new) |
Line voltage | DC 750 V |
Traction | 6 x 120 kW |
Max. speed | 70 km/h |
